TC82AJ plus


With its 82 foot straight telescoping boom, the TC82AJ plus provides rapid point to point access for the most difficult to reach applications. With it’s newly designed high performance boom system, the TC82AJ plus is unmatched in its smooth boom operation and stability aloft. The height and width adjustable track chassis maximizes versatility in both indoor and outdoor projects.

Request a Quote

General Specifications:
Max Working Height 88 ft
Max Platform Height 82 ft
Horizontal Outreach with 220 lbs 48 ft
Horizontal Outreach with 551 lbs 41 ft
Max Platform Capacity 551 lbs
Max Turntable Rotation 450°
Download Spec Sheet



Standard Features:
Features: CHASSIS

  • Powerful track drive with hydraulic braking system
  • Precise manoeuvring via sensitive remote control
  • Outdoor non-marking rubber tracks, with less tread depth the profile enables smooth travelling
  • Hydraulically height- and width-adjustable crawler track drive

STABILIZATION

  • Electrohydraulic stabilizers with automatic levelling and ground pressure sensor system
  • Variable Stabilizer system
    •  wide supported
    •  narrow supported
    • left or right wide/narrow supported
    • front or back wide/narrow supported
  • Tree package, including
    • 4 covers, piston rod (stabilizer)
    • Wear resistant, anti-friction outrigger pads

BOOM SYSTEM

  • Telescopic lower and upper boom
  • All functions available via radio remote control
  • Platform positioning into negative work area up to 16 ft below set up level
  • 180° platform rotation for additional flexibility
  • Fly jib movable by 165°
  • Platform changing system
  • Platform (GRP) including platform support (27.55″ x 27.55″)
    • Attention, machine is not insulated!
  • Coming home function – automatic return of the boom into transport position

POWER SOURCE

  • Diesel engine Kubota Z602 (10,8KW / 14,5HP)
  • Start-stop device for combustion engine via radio control

PRODUCTIVITY, SAFETY, QUALITY

  • Power socket in the platform (115 V / 13 A)
  • USB-Power socket in the platform (5V)
  • Power socket in the platform (12V/5A)
  • Drive operation without platform possible
  • Lockable storage box
  • Protected, internal power track for platform control
  • Hydraulic system filled with biodegradable hydraulic oil
  • High-quality paint in RAL 3020 (red)
    • Hydraulic cylinders in RAL 9006 (white aluminum)
    • Engine unit & component support in RAL 9006 (white aluminum)
  • Hydraulic system protected by pressure relief valves
  • Hydraulic tank, secondary control, connecting cables and hoses are mounted protected
  • Additional hydraulic drive for boom recovery via platform control
  • Color display in the platform control panel
  • Color display at the chassis
  • Hour meter
  • TEUPEN Fuzzy V control technology with new intuitive operating concept
Optional Features:
Options:
  • Custom paintwork, one color, according to RAL scheme, no special colors
  • Custom paintwork, two colors, according to RAL scheme, no special colors
